High capacity PM precision balances:
We would like to present new series of balances based on MonoBLOCK™ technology, offering the highest measurement accuracy within permissible maximum capacities. PM balances assure operation with readability of 0.01g at capacity of 15kg, and with readability of 0.1g at capacity of 50 kg.
Use of the new measuring system, which is a subject matter of patent, guarantees stability of repeatability over time at a range sd<1d. The unique measuring system solution is characterized with great resistance to ambient conditions change.
PM balances offer good ergonomics, wide range of applications and comfort of operation. Modern weighing terminals enable adjusting balance settings to individual requirements of particular operators. Models equipped with 4Y terminal are consistent with CFR21 regulation.
|Product name||Maximum capacity [Max]||Readability [d]||Weighing pan dimensions|
|KR PM 10.C32||10 kg||0,01 g||200×185 mm|
|KR PM 10.4Y||10 kg||0,01 g||200×185 mm|
|KR PM 15.C32||15 kg||0,01 g||200×185 mm|
|KR PM 15.4Y||15 kg||0,01 g||200×185 mm|
|KR PM 25.C32||25 kg||0,1 g||347×259 mm|
|KR PM 35.C32||35 kg||0,1 g||347×259 mm|
|KR PM 35.4Y||35 kg||0,1 g||347×259 mm|
|KR PM 50.C32||50 kg||0,1 g||347×259 mm|
|KR PM 50.4Y||50 kg||0,1 g||347×259 mm|
Maximum capacity [Max]: 10kg
Readability [d]: 0,01g
- new MonoBLOCK sensor;
- unrivalled repeatability of indications;
- weighing of heavy loads with maximum accuracy;
- intuitive operation guaranteed by a membrane keyboard;
- fast mass measurements;
- robust mechanical design – new lower weighing platform;
- improved ergonomics – two types of weighing terminal for selection.
Balance offers possibility of weighing loads outside the weighing platform (so called under-pan weighing). This is an alternative for weighing loads with non-standard dimensions and shapes or those generating magnetic field.
